SYNISON Laboratory LTD
R E V E A L S * the
Innovative & Impressively FLEXIBLE
MOTION PATTERN of Pistons
of the New Piston Rotary Engine:
"THREEE CHIDOT" (Absolute Motion).
{ this video is just a demo;
for a Complete Piston Absolute Position Array (CPAPA)
and/or a Complete Toothing Profile Point Array (CTPPA),
of an Optimized Model, visit: www.synison.gr }
(*) WO/2009/040588: Application Example & Claim 7:
- YELLOW peripheral stripe represents the INTAKE slot
- MAGENTA peripheral stripe represents the EXHAUST slot
- COMBUSTION occurs in motion, via 3 stationary groups of Spark Plugs or
1 Spark Plug on the center of the Rear Face of the Leading Piston (here)
