THE DOT project

SYNISON Laboratory LTD

R E V E A L S * the

Innovative & Impressively FLEXIBLE

MOTION PATTERN of Pistons

of the New Piston Rotary Engine:

"THREEE CHIDOT" (Absolute Motion).

{ this video is just a demo;

for a Complete Piston Absolute Position Array (CPAPA)

and/or a Complete Toothing Profile Point Array (CTPPA),

of an Optimized Model, visit: www.synison.gr }

(*) WO/2009/040588: Application Example & Claim 7:

- YELLOW peripheral stripe represents the INTAKE slot

- MAGENTA peripheral stripe represents the EXHAUST slot

- COMBUSTION occurs in motion, via 3 stationary groups of Spark Plugs or

1 Spark Plug on the center of the Rear Face of the Leading Piston (here)
